Brief specifications
| Type of Zones | 1x zone small 2x zone large |
| Editions | Black (fully black) |
| Position of the knobs | Top side, Front side |
| Dimensions of the module (LxWxH)) | 17.60 ×33.82 ×3.54" / 447 x 859 x 90 mm |
| Automatic pan detection | ✓ |
| Power levels | 0 - 10 + Boost |
| Nominal voltage | 208 VAC / 240 VAC |
| Maximum current | 28.5 A |
| Maximum power | 5,928W (@208VAC) 6,840W (@240VAC) |
| Net Weight | 16 kg |
Downloads
| User manual | |
| Guarantee conditions | |
| Maintenance advice |
Technical downloads
| Colo-I - Technical document | |
| Holepattern, overview Top Side (DXF) | |
| Holepattern, overview Front Side (DXF) | |
| STEP-files |
Design & Installation
| Design & processing guidelines (PDF) | |
| Installation manual (PDF) |
Detailed specifications
Design instructions (cabinet/countertop)
| Minimum countertop depth | Top Side: 600 mm (23.62″) Front Side: 650 mm (25.59″) |
| Minimum cabinet width | 900 mm / 35.43″ |
| Thickness of countertop (original material) | 4-35 mm / 0.16-1.38″ |
| Assistance required? | ✓ |
Electricity
| Type of cooking system | Induction |
| Position of electrical connection | Top-right corner |
| Maximum cable length | 1500 mm / 59.06″ |
| Recommended specifications for electrical wires | 2,5 mm2 |
